SIN DESCRIPCIÓN ASOCIADA
Tipo de luminaria
Acabado
Garantía
Características lumínicas y técnicas
Potencia (W)
15 W
Lúmenes (lm)
CCT (K)
2700 K
CRI
>90
Protección y óptica
-
IP
IP20
-
IK
-
Óptica
-
Low UGR
-
Flicker-free
No
Regulación
Tensión (V)
220V-240V
Dimensiones (mm)
Documentación
FICHA TECNICA
Especificaciones técnicas completas (PDF)
Archivos CAD / BIM
Modelos 2D y 3D para proyectos (.dwg, .rfa)
FOTOMETRIA
Datos de curvas de luz (.ies, .ldt)
Double emission recessed downlights for indoor application. The super warm white LED light source with a diffused light distribution is composed of 36 topled LEDs with CCT of 2700 K and a CRI 90; the source luminous flux is 1563 lm, with a 120.2 lm/W nominal luminous efficacy.
The device body is made of aluminium and features a text white ral 9003 finish, processed by means of coating; the diffuser is made of pmma with a satin finishing treatment; the mounting frame is made of aluminium, with a text white ral 9003 finish, processed by means of coating. The ingress protection degree is IP20;
The total absorbed power is 15 W
The device features protection class II and can be ceiling-mounted, with a 60 mm diameter hole (in plasterboard).
Compliant with the EN 60598-1 standard and its specific provisions.
